7.3 Hydraulics Troubleshooting
Problem Solution
Section
Symptom: Header or reel is not lifting.
Appropriate solenoids not being
energized by activating switch
Contact Dealer.
—
Symptom: Reel and/or conveyor is not turning.
Flow controls adjusted too low
Toggle speed controls on Harvest
Performance Tracker (HPT) display to
increase flow.
Conveyor Speed Adjustment Buttons,
page 79 and
Reel and Disc Speed Switch, page 76
Flow controls adjusted too low
Toggle speed controls on Harvest
Performance Tracker (HPT) display to
increase flow.
Conveyor Speed Adjustment Buttons,
page 79 and
Reel and Disc Speed Switch, page 76
Appropriate solenoid on flow control
block not being energized
Contact Dealer.
—
Relief pressure too low
Check/adjust/clean relief valve.
—
Symptom: Hydraulic oil high-temperature alarm activates.
Hydraulic oil cooling system not
working properly
Check/clean cooling box.
5.9.2 Cleaning Cooler Module, page
284
