215922 381 Revision A
6.4 Transport
Several kits are available which facilitate moving the header from field to field.
6.4.1 Ballast
Ballast kits are for draper headers only.
Initial rear ballast package (MD #B6053): 1 unit (163 kg [360 lb.])
Installation instructions are included.
Table 6.2 Ballast
Header Type
Description
Installed Options
Base Kit
Additional
Kits
Additional
Float Springs
D125X
25 foot, single reel,
double knife, timed
–
00 0
D130XL
30 foot, single reel,
double knife, timed
Transport
10 0
D130XL
30 foot, single reel,
double knife, timed
Transport + upper cross
auger + vertical knives
1
0 MD #B6047
D135XL
35 foot, single reel,
double knife, untimed
Base
1
00
D135XL
35 foot, single reel,
double knife, untimed
Transport
1
0 MD #B6047
D135XL
35 foot, single reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1
0 MD #B6047
D135XL
35 foot, double reel,
double knife, untimed
Base
10 0
D135XL
35 foot, double reel,
double knife, untimed
Transport
1 0 MD #B6047
D135XL
35 foot, double reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1 0 MD #B6047
6.4.2 Towing Harness
The towing harness is used together with the weight box (refer to 6.4.3 Weight Box, page 381) when towing a D1XL or D1X
Series Draper Header equipped with slow speed transport option behind the windrower.
MD #B6048 – Weight box harness only. Includes hitch pin and wiring for use with slow speed header transport option.
Instruction MD #147868 is included in the bundle.
6.4.3 Weight Box
A weight box installed onto the windrower header lift system is required to transport a header behind the windrower.
MD #B6974 – Weight box, narrow transport
A towing harness is required to use the weight box. Refer to 6.4.2 Towing Harness, page 381 for more information.
OPTIONS AND ATTACHMENTS
