Run Screen 1
This is what Run Screen 1 looks like when operating a draper header.
1014944
A
B
C
D
E
F
G
H
H
H
Figure 4.243: Run Screen 1 – Draper Header Display
A - Reel Speed B - Draper Speed C - Knife Speed
D - Reel Pressure E - Draper Pressure F - Knife Pressure
G - Indexing H - Alarm Point
