MacDon M1170NT5 - Installing Forked Caster Wheel

215922 372 Revision A
1034210
1
2
3
A
B
C
A
D
Figure 5.228: Walking Beam Extension Limit Stops – Right Side Shown
Installing Forked Caster Wheel
1019261
A
B
C
Figure 5.229: Caster Wheel Assembly
1. Position axle assembly (B) into wheel (C) and secure it with
wheel nuts (A).
MAINTENANCE AND SERVICING
