215922 322 Revision A
5.14 Annual Service
Complete the following maintenance tasks annually. It is recommended that annual maintenance be done prior to start of
operating season.
• Check the battery charge and fluid level. For instructions, refer to 5.14.1 Batteries, page 322.
• Check the steering linkages. For instructions, refer to 5.14.2 Checking Steering Link Pivots, page 330.
• Check the A/C blower. For instructions, refer to 5.14.3 Air Conditioning Evaporator, page 332.
• Check the antifreeze concentration. For instructions, refer to 5.14.4 Checking Engine Coolant Strength, page 334.
5.14.1 Batteries
A pair of vehicle batteries powers the windrower’s electrical system. Ensure that replacement batteries are of the
correct type.
Install only the type of batteries specified in the table below onto the windrower:
Table 5.4 Battery Specifications
Rating
Group
CCA (min)
Volt
Maximum Dimension
Heavy duty, off-road,
vibration resistant
29H or 31A 760
12
334 x 188 x 232 mm
(13 x 7.4 x 9.13 in.)
Maintaining Battery
CAUTION
Do NOT attempt to service battery unless you have the proper equipment and experience to perform the job. Have it
done by a qualified Dealer.
• Check the battery charge once a year, and more often if operating in cold weather. Hydrometer readings should be
1.260 to 1.300. Readings below 1.250 indicate charging is required. For instructions, refer to Charging Battery, page
324.
• Keep the batteries clean by wiping them with a damp cloth.
• Keep all connections clean and tight. Remove any corrosion and wash the terminals with a solution of baking soda and
water. A light coating of grease on the terminals (after the cables are attached) will reduce corrosion.
• To prolong battery life, store batteries fully charged and at -7° to +26°C (+20° to +80°F). Check the voltage after storage
and recharge the batteries as needed according to battery and charger manufacturer recommendations.
• Do NOT stack storage batteries on top of each other.
• Test the batteries every 4–6 months and recharge them if necessary.
• Disconnect the battery ground if storing the windrower for more than 3 months.
Opening Battery Cover
DANGER
To prevent bodily injury or death from the unexpected startup of the machine, always stop the engine and remove the
key from the ignition before leaving the operator’s seat for any reason.
1. Shut down the engine, and remove the key from the ignition.
2. Open the hood. For instructions, refer to 5.3.1 Opening Hood, page 239.
MAINTENANCE AND SERVICING
