2.4 Component Location
Maintaining and servicing the windrower is easier if you are familiar with the location of the windrower’s main
components.
1034048
A
B
C
D
E
F
G
H
J
J
K
L
M
N
E
F
M
Figure 2.3: Cab-Forward View
A - Header Lift Leg B - Header Float Springs C - Operator’s Station
D - Windshield Wiper E - Turn Signals / Hazard Lights F - Tail lights Engine-Forward
G - Field/Road Lights H - Handholds J - Mirror
K - Door L - Maintenance Platform M - Beacon Lights
N - Flood Lights x 4
