215922 135 Revision A
Figure 4.38: Console
8. If more tractive (lugging) power is required (e.g., when
driving up a ramp, up a hill, or out of a ditch):
a. Move GSL (A) closer to NEUTRAL.
b. Reduce max speed setting to 16 km/h (10 mph) by
holding the shift button on the GSL while scrolling
downwards, or by reducing the max speed setting
using the QuickMenu. For instructions, refer to
Adjusting Ground Speed Limit, page 129.
9. Once the lugging condition no longer exists:
a. Set GSL (A) to NOT MORE THAN HALF maximum
forward speed.
Driving in Reverse in Engine-Forward Mode
WARNING
Back up slowly. Hold the steering wheel at the bottom and turn the wheel in the direction you want the rear of the
machine to travel.
Figure 4.39: Console
1. Move throttle lever (A) to a mid-range position.
NOTE:
Reversing in low speed range and at reduced engine speed
is recommended since steering will be less sensitive than at
higher speed settings.
2. Move ground speed lever (GSL) (B) rearward to
desired speed.
DANGER
Ensure that all bystanders have cleared the area.
Figure 4.40: Steering the Windrower
3. Steer as shown.
OPERATION
