To program a float setting for each of the deck shift positions, follow these steps:
Figure 4.238: GSL
1. Start the engine, and use HEADER TILT switches (A) and (B)
on the ground speed lever (GSL) to set header tilt to the
mid-range position.
Figure 4.239: Header Engage Switch
2. Engage the header by pushing and holding HEADER
ENGAGE switch (A) down, and pulling up on collar (B).
Figure 4.240: Header Deck Shift Switches
3. Select one of the following deck positions using the DECK
SHIFT switches on the operator’s console:
• Right-side delivery (A)
• Center delivery (B)
• Left-side delivery (C)
