215922 276 Revision A
Figure 5.57: Gearbox Lubricant Filler
6. If lubricant is needed, remove breather cap (A) and add
lubricant until it runs out of the level check port.
NOTE:
For oil requirements, refer to the inside back cover.
Figure 5.58: Gearbox Lubricant Check Plug
7. Replace oil level check plug (A) and the breather cap and
tighten both.
8. Operate the engine at low idle and check for leaks at oil
level check plug (A).
MAINTENANCE AND SERVICING
