215922 288 Revision A
Figure 5.82: Right Cooler Module
4. At the right (cab-forward) cooler module, with the screen
door open, clean the debris from screen (A) with
compressed air.
Figure 5.83: Right Cooler Module
5. Close screen door (B) and secure it with latch (A).
MAINTENANCE AND SERVICING
