215922 313 Revision A
1036141
A
B
C
Figure 5.123: DEF Fluid Filter Housing
9. Remove and discard clip (A) that secures fluid filter
housing (B).
10. Pull old fluid filter housing (B) off of the suction line.
11. Remove and discard existing O-ring (C).
1036141
A
B
C
Figure 5.124: DEF Fluid Filter Housing
12. Install new O-ring (C) (supplied with filter housing) onto the
supply line.
NOTE:
The DEF tank fluid filter housing (MD #291162) includes
O-ring (C), clip (A), and a 40 micron filter (not shown).
13. Push new DEF tank liquid filter housing (B) onto the line
and secure it with new clip (A).
MAINTENANCE AND SERVICING
