MacDon M1170NT5 - Page 464

215922 444 Revision A
J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN Description
Detail
91 19
Stop
Engine
Red
1515
Accelerator Pedal
Position 1
SAE J1939 Multiplexed
Accelerator Pedal or Lever Sensor
System - Received network data
in error
94 3
Check
Engine
Amber
546
Engine Fuel Delivery
Pressure
Fuel Delivery Pressure Sensor
Circuit - Voltage above normal, or
shorted to high source
94 4
Check
Engine
Amber
547
Engine Fuel Delivery
Pressure
Fuel Delivery Pressure Sensor
Circuit - Voltage below normal, or
shorted to low source
95 16
Check
Engine
Amber
2372
Engine Fuel Filter
Differential Pressure
Fuel Filter Differential Pressure -
Data valid but above normal
operating range - Moderately
Severe Level
97 3
Check
Engine
Amber
428
Water In Fuel Indicator
Water in Fuel Indicator Sensor
Circuit - Voltage above normal, or
shorted to high source
97 4
Check
Engine
Amber
429
Water In Fuel Indicator
Water in Fuel Indicator Sensor
Circuit - Voltage below normal, or
shorted to low source
97
15
Water
in Fuel
Amber
(Blinking)
418
Water In Fuel Indicator
Water in Fuel Indicator - Data
valid but above normal operating
range - Least Severe Level
97 16
Water
in Fuel
Amber
1852
Water In Fuel Indicator
Water in Fuel Indicator - Data
valid but above normal operating
range - Moderately Severe Level
100 1
Eng Oil
Press
Red
415
Engine Oil Pressure
Engine Oil Rifle Pressure - Data
valid but below normal
operational range - Most Severe
Level
100
2
Check
Engine
Amber
435
Engine Oil Pressure
Engine Oil Rifle Pressure - Data is
erratic, intermittent, or incorrect
100 3
Check
Engine
Amber
135
Engine Oil Pressure
Engine Oil Rifle Pressure 1 Sensor
Circuit - Voltage above normal, or
shorted to high source
100 4
Check
Engine
Amber
141
Engine Oil Pressure
Engine Oil Rifle Pressure 1 Sensor
Circuit - Voltage below normal, or
shorted to low source
100 18
Check
Engine
Amber
143
Engine Oil Pressure
Engine Oil Rifle Pressure - Data
valid but below normal operating
range - Moderately Severe Level
101 0
Stop
Engine
Red
556
Engine Crankcase Pressure
Crankcase Pressure - Data valid
but above normal operational
range - Most Severe Level
101
2
Check
Engine
Amber
1942
Engine Crankcase Pressure
Crankcase Pressure - Data is
erratic, intermittent, or incorrect
101 3
Check
Engine
Amber
1843
Engine Crankcase Pressure
Crankcase Pressure Circuit -
Voltage above normal, or shorted
to high source
REFERENCE
