MacDon M1170NT5 - Page 52

215922 32 Revision A
Table 2.1 M1170NT5 (continued)
Header Drive
Knife/Disc
Pump
Piston, 53 cc (3.23 cu. in.)
Max pressure
37,921 kPa (5500 psi)
Flow
151.4 L/min (40 gpm)
Reel
Pump
Gear, 25.2 cc (1.54 cu. in.)
Max pressure
23,994 kPa (3480 psi)
Flow
75.7 L/min (20 gpm)
Draper
Pump
Gear, 19.3 cc (1.18 cu. in.)
Max pressure
23,994 kPa (3480 psi)
Flow
53 L/min (14 gpm)
Lift/Fan Drive
Pump
Piston, 60 cc (3.66 cu. in.)
Max pressure
22,063 kPa (3200 psi)
Flow
0–170.3 L/min (45 gpm)
Header Lift/Tilt
Type
Hydraulic double acting cylinders
Max lift capacity 3810 kg (8400 lb.)
Header Float
Adjustment Fully in-cab adjustable
Automatic
Memory for 3 float settings (deck shift positions on draper)
Options
External booster spring (up to 2 per side)
Deluxe Cab
Suspension
4 point spring/shock
Dimensions
Width
1767 mm (69.6 in.)
Depth
1735 mm (68.3 in.)
Height
1690 mm (66.5 in.)
Seat
Operator
Leather, adjustable air ride suspension, seat belt,
heated/cooled, lateral isolation, adjustable front cushion
Training Leather, folding, cab mounted, seat belt
Windshield wiper
Front
990 mm (39 in.) blade, washer equipped
Rear
560 mm (22 in.) frameless blade, washer equipped
Heater
11.10 kW (37,900 Btu/hr)
Air conditioning
8.73 kW (29,800 Btu/hr)
Electrical outlets
12 V DC
6
USB
2
Radio
AM/FM/DVD/USB/Bluetooth radio, antenna, microphone,
and two factory-installed speakers
Mirrors
Two power adjustable outside (field use), two manually adjustable
(transport mode)
Sun shades
Front and rear
PRODUCT OVERVIEW
