3-98
9. Verify that the four outrigger setting lamps (3) on the outrigger
display are flashing in red.
NOTES
On the outrigger display, the boom stowing lamp (1) (green) is
illuminated and four outrigger extension lamps (2) and four
outrigger setting lamps (3) are flashing in red.
10 Push down an outrigger extension switch or two of them at the
same time to the “IN” (upward) side.
When the extension cylinder fully retracts and the inner box is at
its shortest, return the switch to the “NEUTRAL” position.
Operate the remaining switches in the same way and make the
inner box of the four outriggers to their shortest. Return the
switch to the “NEUTRAL” position.
11. Turn the starter switch to the “OFF” position.
The engine stops.
