Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 111
5.2.20 Slack Cable Detection
IMPULSE
®
•VG+ Series 4 offers Slack Cable Detection for hoist applications. The Slack Cable condition is
detected when the torque output is drastically reduced and has dipped below a set-point (C11-03) level. When
Slack Cable condition occurs, the output action is defined by the C11-02 which has six selections.
The Slack Cable Detection is not executed, unless both of the following conditions are true:
• The output frequency is between C11-04 and C11-06.
• The Slack Cable Detection delay time is between C11-05 and C11-07.
Setup Procedure:
• Set the Slack Cable Detection torque level (C11-03), by lowering the hoist without load at a constant speed that
the hoist would normally run during the operation. Monitor and record the torque reference (U01-09). Repeat
the above operation several times to ensure an accurate reading.
• Then set C11-03 = [(U01-09)-2].
• Enable Slack Cable Detection by setting the C11-01 to 1.
• Select output action when Slack Cable is detected by defining C11-02.
Table 5-36: Slack Cable Detection
Parameter Display Function Range Default
C11-01 Slack Cable (For Hoist Application) Determines whether Slack
Cable Detection is enabled.
0–2 0
0 Disabled
1 Enabled
2 Enabled by MFDI
C11-02 Action at SLC Multi-function output that occurs at Slack Cable
Detection. For all Selections, RAISE command is
permitted (MFDO = 28).
0–5 2
0 No Action Alarm Only
1 No Act/C3-04 Next LOWER command is at Lower Limit 1 speed
(C03-04).
2 Decel/C3-04 Decelerate to Lower Limit 1 Speed C03-04 by
C03-05. Continued LOWER commands allowed,
but at C03-04 as max speed.
3 Decel/No Opr Decelerate to Lower Limit 1 Speed C03-04 by
C03-05. Continued LOWER commands are not
allowed.
4 Dec Stop/C3-04 Decel (by C03-06) to stop. Continued LOWER
commands allowed, but only at C03-04 speed.
5 Dec Stop/No Opr Decel (by C03-06) to stop.
Continued LOWER commands are not allowed.
C11-03 SLC Detect Torq Percentage of Output Torque below which the
enabled Slack Cable Detection is activated-as
long as the Frequency output is between C11-04
and C11-06, and the delay time is between C11-
05 and C11-07.
-50–100% 30
C11-04 SLC Detect Spd 1 The Frequency Output that is required for the
enabled Slack Cable Detection to be activated. It
corresponds to Slack Cable Detection Delay Time
1 (C11-05).
0–E01-04 Hz 2
