Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 94
5.2.12.4 Clearing a Load Check Alarm (LC)
A Load Check alarm/fault can be reset by pressing the RESET key on the keypad.
Table 5-28: Load Check II Parameter Settings
Parameter Display Function Range Default
C05-01 Load Check Determines whether Load Check is enabled. 0–9 0
0 Disabled Disables Load Check II Function
1 Hold & Measure Checks per Holding and Testing Time
3 Immediate Immediately faults when I/T level is exceeded
9 LC Set Up Set up Load Check II
C05-02 LC Alarm Action Action at Load Check alarm or fault 0–5 4
0 Alarm Only L.C. blinking, can continue raising
1 Decel to Stop Allows lower only
2 Coast to Stop Allows lower only
3 Fault Stop Fault contacts change state - requires reset
4 Use B3-03 Method Allows Lower only
5 B03-03 with Reset Stopping method is B3-03. Allows Lower Only.
Alarm will be reset when load is lowered.
C05-03 Holding Time Sets the time to hold the output frequency
allowing the output current/torque to stabilize.
0.00–2.55 sec 0.15
C05-04 Testing Time Sets the time (after the Holding Time) for
comparing output current/torque to values for
a particular LC Zone being tested.
0.00–2.55 sec 0.25
C05-05 I/T Margin Acc Sets the margin for Load Check detection
during acceleration. A setting of 00 is the most
sensitive.
0–50% 5
C05-07 I/T Margin Sets the margin for Load Check detection at
speed agree. A setting of 00 is the most
sensitive.
0–20% 5
C05-08 Alarm Speed Sets the maximum lowering speed after an LC
alarm.
0.0–30.0 Hz 6.0
C05-09 I/T Level 01 Current/Torque for Zone 01 0–250% 0
C05-10 I/T Level 02 Current/Torque for Zone 02 0–250% 0
C05-11 I/T Level 03 Current/Torque for Zone 03 0–250% 0
C05-12 I/T Level 04 Current/Torque for Zone 04 0–250% 0
C05-13 I/T Level 05 Current/Torque for Zone 05 0–250% 0
C05-14 I/T Level 06 Current/Torque for Zone 06 0–250% 0
C05-15 I/T Level 07 Current/Torque for Zone 07 0–250% 0
C05-16 I/T Level 08 Current/Torque for Zone 08 0–250% 0
C05-17 I/T Level 09 Current/Torque for Zone 09 0–250% 0
C05-18 I/T Level 10 Current/Torque for Zone 10 0–250% 0
C05-19 I/T Level 11 Current/Torque for Zone 11 0–250% 0
C05-20 I/T Level 12 Current/Torque for Zone 12 0–250% 0
C05-21 I/T Level 13 Current/Torque for Zone 13 0–250% 0
