Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 82
5.2.1 Quick Stop™
The Quick Stop Function provides an automatic Alternate Deceleration at Stop.
NOTE: The Quick Stop Deceleration time differs from the normal deceleration time and is applied only when the
RUN command is removed.
Table 5-15: Quick Stop Parameter Settings
* Initial value is determined by X-Press Programming (Table 4-6 on page 59, Table 4-7 on page 60 or Table 4-8 on page 61).
Figure 5-7: Quick Stop
Parameter Display Function Range Default
C01-01 Quick Stop Determines whether Quick Stop is enabled 0, 1 0*
0 Disabled
1 Enabled
C01-02 Quick Stop Time Deceleration time during Quick Stop function. 0.0–25.5 sec 1.0
