IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 33
3.2
Suggested Circuit Protection and Wire Size
In order to comply with most safety standards, circuit protective devices should be used between the incoming
three-phase power supply and the IMPULSE
®
•G+ & VG+ Series 4. These devices can be thermal, magnetic, or
molded-case circuit breakers (MCCB); or “slow-blow” type time-delay fuses.
NOTE: The following are recommendations based on the rated capacity of the VFD. Per NEC guidelines, circuit
protection and wiring can be selected based on the capacity of the motor.
Table 3-1: Wire Sizing for 230 V Class
1) NFPA 70 National Electric Code 2011. 430.122(a) and Table 610-14(a) 40°C, 60-minute, copper 50°C ambient
2) NFPA 70 National Electric Code 2011. Table 250.122.
3) NFPA 70 National Electric Code 2011. Table 430.52 (selected based on motor FLA).
4) NFPA 40 National Electric Code 2011. Table 315(b)(2)(a).
Model Number
(-G+/VG+S4)
Recommended Circuit Protection Recommended Wire Size (AWG)
1, 4
Continuous
HD Input
Amps
Time Delay
Input Fuse
(A)
Time Delay
Input Fuse
Class
Inverse Time Molded/
Case Circuit Breaker (A)
3
Power Circuit Wiring
Control
Wiring
Ground
Copper
2
2003 2.9 5 CC 15 14 to 10 18 to 16 14 to 10
2005 5.8 10 CC 15 14 to 10 18 to 16 14 to 10
2007 7.0 12 CC 20 14 to 10 18 to 16 14 to 10
2008 7.5 15 CC 20 14 to 10 18 to 16 14 to 10
2011 11.0 20 CC 30 14 to 10 18 to 16 14 to 10
2014 15.6 30 CC 40 14 to 10 18 to 16 14 to 10
2017 18.9 35 CC 50 12 to 10 18 to 16 12 to 10
2025 28.0 50 J 70 10 to 6 18 to 16 10 to 8
2033 37.0 70 J 100 8 to 6 18 to 16 10 to 8
2047 52.0 100 J 150 6 to 4 18 to 16 8 to 6
2060 68.0 125 J 175 4 to 2 18 to 16 6 to 4
2075 80.0 150 J 200 4 to 2 18 to 16 6 to 4
2085 82.0 150 J 225 2 to 1/0 18 to 16 6 to 4
2115 111 200 J 300 2 to 1/0 18 to 16 4
2145 136 250 J 350 1/0 to 2/0 18 to 16 4 to 2
2180 164 300 J 450 1/0 to 2/0 18 to 16 4 to 1/0
2215 200 350 J 500
250
2-2/0
18 to 16 3 to 300
2283 271 500 J 700
350
2-3/0
18 to 16 2 to 300
2346 324 600 J 1000
400
2-250
18 to 16 1 to 350
2415 394 700 J 1000
400
2-250
18 to 16 1 to 350
CAUTION
The following guidelines are suggested values. Always conform to local electrical codes and wiring practices.
