IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 63
4.3.2.9 User Parameters (A02-01 through 32)
The user can select up to 32 parameters for quick-access programming. By setting the user access level (A01-01)
to “User Program”, only the parameters selected in the A02 parameters can be accessed by the user. To assign a
parameter as a user parameter, go to the A02 level in the initialize menu. Once the A02 parameters are set and
A01-01 is programmed to “User Program”, only the parameters visible in the program menu will be assigned to an
A02 parameter.
The A02 group is pre-loaded with the settings listed in Table 4-10, based on A01-03.
Table 4-10: Application Quick Set
A01-03 0 1 2
Favorite Traverse Std Hoist NLB Hoist
- B01-01: Speed 1 B01-01: Speed 1 B01-01: Speed 1
A02-01 B01-02: Speed 2 B01-02: Speed 2 B01-02: Speed 2
A02-02 B01-03: Speed 3 B01-03: Speed 3 B01-03: Speed 3
A02-03 B01-04: Speed 4 B01-04: Speed 4 B01-04: Speed 4
A02-04 B01-05: Speed 5 B01-05: Speed 5 B01-05: Speed 5
A02-05 B03-04: Change Rotation B03-04: Change Rotation B03-04: Change Rotation
A02-06 B05-01: Accel Time 1 B05-01: Accel Time 1 B05-01: Accel Time 1
A02-07 B05-02: Decel Time 1 B05-02: Decel Time 1 B05-02: Decel Time 1
A02-08 C01-03: Reverse Plug C02-01: MicroSpd Gain 1 C01-01: Quick Stop
A02-09 C01-04: Rev-Plg Dec Time C03-01: UL1 Speed C01-02: Quick Stop Time
A02-10 C01-05: Rev-Plg Acc Time C03-04: LL1 Speed C02-01: MicroSpd Gain 1
A02-11 C02-01: MicroSpd Gain 1 C06-01: Swift-Lift C03-01: UL1 Speed
A02-12 E01-03: V/f Selection C06-02: SwiftLift FWDSpd C03-04: LL1 Speed
A02-13 E02-01: Motor Rated FLA C06-03: SwiftLift REVSpd C06-01: Ultra-Lift
A02-14 H01-06: Terminal S6 Select C06-04: SL FWD Current/Torque C06-02: UltraLift FWDSpd
A02-15 H01-07: Terminal S7 Select C06-05: SL REV Current/Torque C06-03: UltraLift REVSpd
A02-16 H01-08: Terminal S8 Select C06-06: SL Enabling Spd C06-04: UL FWD Torque
A02-17 H02-03: Terminal M5/M6 Select E01-03: V/F Selection C06-05: UL REV Torque
A02-18 H03-02: Terminal A1 Function Select E01-04: Max Frequency C08-03: Min Brk Rel Trq
A02-19 H04-02: Terminal FM Gain E02-01: Motor Rated FLA C08-10: Load Float Time
A02-20 - H01-06: Terminal S6 Select C08-11: Brake Set Delay
A02-21 - H01-07: Terminal S7 Select C08-14: Brake Hold Speed
A02-22 - H01-08: Terminal S8 Select F01-01: PG1 Pulses/Rev
A02-23 - H02-03: Terminal M5/M6 Select F01-05: PG1 #Gear Teeth2
A02-24 - H03-02: Terminal A1 Function Select H01-06: Terminal S6 Select
A02-25 - H04-02: Terminal FM Gain H01-07: Terminal S7 Select
A02-26 - - H01-08: Terminal S8 Select
A02-27 - - H02-03: Terminal M5/M6 Select
A02-28 - - H03-02: Terminal A1 Function Select
A02-29 - - H04-02: Terminal FM Gain
A02-30 - - -
A02-31 - - -
A02-32 - - -
