IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 141
5.5.4 Digital Output (DO-A3 or S4IO) Option Card Setup
Selects the multi-function digital output settings for the DO-A3 and S4IO option cards.
Table 5-66: DO-A3/S4IO Parameter Settings
* See Table 5-75 on page 152 for MFDO selections.
Parameter Display
Terminal Designation
Range Default
DO-A3 S4IO
F05-01* DO Ch1 Select M1-PC O1-O2 0–148 F
F05-02* DO Ch2 Select M2-PC O3-O2 0–148 F
F05-03* DO Ch3 Select M3-PC O4-O5 0–148 F
F05-04* DO Ch4 Select M4-PC O6-O5 0–148 F
F05-05* DO Ch5 Select M5-PC - 0–148 F
F05-06* DO Ch6 Select M6-PC - 0–148 F
F05-07* DO Ch7 Select M1-M2 - 0–148 F
F05-08* DO Ch8 Select M3-M4 - 0–148 F
F05-09 DO Function Sel Selects how the DO-A3 option card will work with
the VFD.
0–2 2
0 8ch Individual
1 Binary Output
2 8ch Selected
