Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 142
Table 5-67: DO-A3 Output Mode Selection
F05-09 Output Type Terminals Output Contents
0 8 –Channel
Individual (Fixed
Data)
TD5 – TD11 OverCurrent (SC, OC, GF)
TD6 – TD11 OverVoltage (OV)
TD7 – TD11 Drive Overload (OL2, OH, OH1)
TD8 – TD11 Fuse Blown (PUF)
TD9 – TD11 OverSpeed (OS-1, OS-2)
TD10 – TD11 Motor Overload (OL1)
TD1 – TD2 Brake Release
TD3 – TD4 Limit Switch (UL1, UL2, UL3, LL1, or LL2)
1 Binary Coded TD5 – TD11 (Bit 0) Bit 3, 2, 1, 0 Output Bit 3, 2, 1, 0 Output
0000 No Fault 1000 EF (ALL)
0001 SC, OC, GF 1001 CPF (ALL)
TD6 – TD11 (Bit 1) 0010 OV 1010 oL1
0011OL21011BE7
0100 OH, OH1 1100 UV (ALL)
TD7 – TD11 (Bit 2) 0101 OS-1, OS-2 1101 DEV-1, DEV-2
0110 PUF 1110 PGO
TD8 – TD11 (Bit 3)
0111 LF 1111 Not Used
TD9 – TD11 Minor Fault (Alarm)
TD10 – TD11 Inverter Ready
TD1 – TD2 Brake Release
TD3 – TD4 Limit Switch (UL1, UL2, UL3, LL1, or LL2)
2 8-Channel
Selectable
TD5 – TD11 F05-01 (See Table 5-76 for output selections)
TD6 – TD11 F05-02 (See Table 5-76 for output selections)
TD7 – TD11 F05-03 (See Table 5-76 for output selections)
TD8 – TD11 F05-04 (See Table 5-76 for output selections)
TD9 – TD11 F05-05 (See Table 5-76 for output selections)
TD10 – TD11 F05-06 (See Table 5-76 for output selections)
TD1 – TD2 F05-07 (See Table 5-76 for output selections)
TD3 – TD4 F05-08 (See Table 5-76 for output selections)
