IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 61
Table 4-8: Hoist NLB (A01-03 = 2) for VG+S4 Models
Parameter Description
A01-04 =
012345678
2-Speed
Multi-
Step
3-Speed
Multi-
Step
5-Speed
Multi-
Step
2-Step
Infinitely
Variable
3-Step
Infinitely
Variable
Uni-Polar
Analog
Bi-Polar
Analog
Industrial
Coms
RS485/
RDSI
Coms
B01-01 Speed 1 20.00 15.00 6.00 6.00 6.00 0.00 0.00 15.00 0.00
B01-02 Speed 2 60.00 30.00 15.00 0.00 0.00 0.00 0.00 30.00 0.00
B01-03 Speed 3 0.00 60.00 30.00 0.00 0.00 0.00 0.00 60.00 0.00
B01-04 Speed 4 0.00 0.00 45.00 0.00 0.00 0.00 0.00 0.00 0.00
B01-05 Speed 5 0.00 0.00 60.00 0.00 0.00 0.00 0.00 0.00 0.00
B01-06–16 Speed 6–16 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
B01-17 Jog Ref 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00 6.00
B01-18 Ref Priority 000001101
B02-03 Ref. Lower Limit 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
B03-01Freq. Ref. Select111111132
B03-02Run Cmd Select 111111132
B03-03Stopping Method666666666
B05-01 Accel Time 1 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
B05-02 Decel Time 1 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
C01-01 Quick Stop 111111111
C03-07Action @ LL1/UL2222222222
C08-10 Load Float Time 10 10 10 10 10 10 10 10 10
C13-12Index Brake Ctrl 222222222
D09-01 S-Curve Accel at Start 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
D09-02 S-Curve Accel at End 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
D09-03 S-Curve Decel at Start 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
E01-03V/f Selection FFFFFFFFF
H01-01 Terminal S1 Select 80 80 80 80 80 80 80 80 F
H01-02 Terminal S2 Select 81 81 81 81 81 81 81 81 F
H01-03Terminal S3 Select00054FFFF
H01-04Terminal S4 SelectF11F5FFFF
H01-05Terminal S5 SelectFF2FFFFFF
H01-06Terminal S6 SelectFF3FFFFFF
H01-07Terminal S7 SelectFFFFFFFFF
H01-08Terminal S8 SelectFFFFFFFFF
H02-01Terminal M0/M1 Select000000000
H02-02Terminal M2/M3 Select000000000
H02-03 Terminal M5/M6 Select 78 78 78 78 78 78 78 78 78
H03-01Terminal A1 Signal Level000000100
H03-02Terminal A1 Select000000000
H03-06 Terminal A3 Select 1F 1F 1F 1F 1F 1F 1F 1F 1F
H03-10 Terminal A2 Select 1F 1F 1F 1F 1F 1F 1F 1F 1F
