Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 154
* This output does not have an inverse output
** Contact will open when power is disconnected
2D Lower Limit 1 ON: LL1 is detected
OFF: Normal operation
2E Lower Limit 2 ON: LL2 is detected
OFF: Normal operation
30 Lower Limit ON: LL1 or LL2 is detected
OFF: Normal operation
31 Up/Low Limit ON: UL1, UL2, UL3, LL1, or LL2 is detected
OFF: Normal operation
32 Snap Shaft ON: VFD has detected a Snap Shaft
OFF: Normal operation
34 Index Complete ON: Index move is complete
OFF: Normal operation or Index move is not complete
35 Ready for F-Ref ON: C08-04 timer has expired or Brake Answerback is detected H01-xx = 58
OFF: Normal operation or VFD detected a BE1, BE2, BE4 alarm or is stopped.
36 Fan Alrm Det ON: VFD detects that the internal cooling fan has failed
OFF: Normal operation
37 Maintenance ON: Maintenance Timer U01-52 ≥ C12-05
OFF: Normal operation or the Maintenance Timer U01-52 < C12-05
38 Spd Lim @ T Cont ON: Speed Limit has been reached while using Torque Control
OFF: Speed Limit has not been reached when using Torque Control
39 Drive Enable ON: VFD is Enabled
OFF: VFD Enable (H01-xx =65) is not active
3B Watt-hour Pulse ON: Watt-hour time is reached (based on H02-06), the contact will close for 200 ms
OFF: Watt-hour time has not been reached
3D Fault or Alarm ON: Fault or Alarm condition is detected
OFF: Normal operation
3E Overspeed ON: Overspeed condition is detected
OFF: Normal operation
3F Klixon ON: Klixon alarm is detected (H01-xx = 56 or 57 is active)
OFF: Normal operation
40 through FF
Flt Annunciate
ON: Specific fault condition detected (see Section 5.6.4 on page 155)
OFF: Normal operation
102 through 1FF** Parameter Settings 2 through FF with inverse output.
Display Function
