Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 156
Table 5-77: Fault Annunciate Worksheet
First digit from the left Second digit from the left
01
Set 1 0 1 BE8 BE6 BE5 BE3 BE2 BE1
Binary
Number
01
First digit from the left Second digit from the left
10
Set 2 1 0 OT1 OT2 LL1 LL2 UL1 UL2
Binary
Number
10
First digit from the left Second digit from the left
11
Set 3 1 1 SLC BE4 BE3 BE2 BE1 BE0
Binary
Number
11
