Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 249
Table B-2: IEC/EN61800-3 Filters (Manufacturer: Schaffner) – 460 V Class
* Connect two of the same EMC filters in parallel.
VFD Model
Filter Data (Manufacturer: Schaffner)
Schaffner Type
Rated
Current
(A)
Weight
lb (kg)
Dimensions
W x D x H (in)
[W x D x H (mm)]
Mounting
Dimensions
Y x X (in)
[Y x X (mm)]
Figure
4001
FS5972-10-07 10 2.7 (1.2)
5.6 x 1.8 x 13.0
(141 x 330 x 46)
4.5 x 12.3
(115 x 313)
B-5
4003
4004
4005
4007
FS5972-18-07 18 2.9 (1.3)
5.6 x 1.8 x 13.0
(141 x 330 x 46)
4.5 x 12.3
(115 x 313)
4009
4014
FS5972-35-07 35 4.6 (2.1)
8.1 x 2.0 x 14.0
(206 x 355 x 50)
6.9 x 13.2
(175 x 336)
4018
4024
4031
FS5972-60-07 60 8.8 (4)
9.3 x 2.6 x 16.1
(236 x 408 x 65)
8.0 x 15.4
(205 x 390)
4039
4045
4060
FS5972-100-35 100 16.5 (3.4)
3.5 x 5.9 x 13.0
(90 x 330 x 150)
2.6 x 10.0
(65 x 255)
B-6
4075
4091
FS5972-170-35 170 10.4 (6.0)
4.7 x 6.7 x 17.8
(120 x 451 x 170)
4.0 x 14.4
(102 x 365)
4112
4150
4180 FS5972-250-37 250 25.8 (11.7)
5.1 x 9.5 x 24.0
(130 x 610 x 240)
3.5 x 19.6
(90 x 498)
4216
FS5972-410-99 410 23.1 (10.5)
10.2 x 4.5 x 15.2
(260 x 386 x 115)
9.3 x 4.7
(235 x 120)
B-7
4260
4304
4370
FS5972-600-99 600 24.3 (11)
10.2 x 5.3 x 15.2
(260 x 386 x 135)
9.3 x 4.7
(235 x 120)
4450
4605 FS5972-800-99 800 69.4 (31.5)
11.8 x 6.3 x 28.2
(300 x 160 x 716)
10.8 x 8.3
(275 x 210)
4810 FS5972-600-99* 600 24.3 (11)
10.2 x 5.3 x 15.2
(260 x 135 x 386)
9.3 x 4.7
(235 x 120)
41090 FS5972-800-99* 800 69.4 (31.5)
11.8 x 28.2 x 6.3
(300 x 716 x 160)
10.8 x 8.3
(275 x 210)
