Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 251
Table B-3: EN 61800-3 Filters (Manufacturer: Block) – 230 V Class
VFD Model
Filter Data (Manufacturer: Block)
Block Type
Rated
Current
(A)
Weight
lb (kg)
Dimensions
W x D x H (in)
[W x D x H (mm)]
Mounting
Dimensions
Y x X (in)
[Y x X (mm)]
Figure
2003
FB-40008A 8 5.1 (2.3)
5.5 x 2 x 11.9
(140 x 50 x 301)
4.7 x 11.2
(120 x 285)
B-8
2005
2007
2008
FB-40014A 12 5.3 (2.4)
5.5 x 2 x 11.9
(140 x 50 x 301)
4.7 x 11.2
(120 x 285)
2011
2014
FB-40025A 25 6.6 (3.0)
5.5 x 2.2 x 11.9
(140 x 55 x 301)
4.7 x 11.2
(120 x 285)
2017
2025
FB-40060A 60 9.9 (4.5)
3.3 x 5.3 x 12.2
(85 x 135 x 310)
2.4 x 10.0
(60 x 255)
B-9
2033
2047
2060 FB-40072A 72 10.4 (4.7)
3.3 x 5.3 x 12.2
(85 x 135 x 310)
2.4 x 10.0
(60 x 255)
2075 FB-40105A 105 11.7 (5.3)
3.7 x 5.9 x 12.8
(95 x 150 x 325)
2.6 x 10.0
(65 x 255)
2085
FB-40170A 170 20.7 (9.4)
5.1 x 7.1 x 17.3
(130 x 181 x 440)
4.0 x 14.4
(102 x 365)
2115
2145
2180 FB-40250A 250 27.3 (12.4)
6.1 x 8.7 x 20.7
(155 x 220 x 525)
4.9 x 17.1
(125 x 435)
2215
FB-40414A 415 58.4 (26.5)
11.8 x 5.1 x 19.7
(300 x 130 x 500)
11.0 x 13.4
(280 x 340)
B-10
2283
2346
2415 FB-40675A 675 62.8 (28.5)
11.8 x 5.1 x 19.7
(300 x 130 x 500)
11.0 x 13.4
(280 x 340)
