Mazda 121 - Page 368

J
TRANSAXLE
01E0JX-121
20. Measure
the
preload
as follows. Set
the differential
assem-
bly
into the clutch
housing.
21. lnstall the
kansaxle
case onto
the clutch
housing
Tlght€ning
torque:
t9-26 N.m
(1.9-2.6
m-kg, 14-19
ft-lb)
22.
Install the SST to
the differential
side
gear
through
the trans-
axle case.
Note
.
Procadurc 23
work wilh
a
pull
scale'
.
Prccedure 24
work
with a iorque
wrsnch.
23.
Turn the SST
(preload
anachmet
)
with a
pull
scale
Readjust the SST
(prsload
adaptor)
until
the specified
preload
when not apply.
Preload: 0,5-0.7
Nm
(5-7.6
cm-kg,
4'3-6.6
innb)
Pull scale: 500-760
g (17.7-26'8 oz)
24. Turn the
SST with a
torque
wrench.
Readjust lhe
SST
(Preload
adaptor)
until
the specified
preload
when
not aPPlY.
Pleload: 0.5-0.7
l,l'rn
(5-7.6
cm-kg,
4.3-6'6 in'lb)
25. Remove the SST.
26. Remove
the transaxle
case
and then
the ditferential
as-
semory.
!:1
t/
@
J-44
