McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
Section Page
McHale Fusion 2 contents section
02-vi
13. Drive Systems
13.1 Gearbox……………………………………………………………. 13-2
13.2 Chamber drive side……………………………………………… 13-2
13.3 Chopper/ pick up drive………………………………………….. 13-5
13.4 Chains and belts………………………………………………….. 13-6
13.5 Roller locations…………………………………………………… 13-7
13.5.1 Baler chamber rollers…………………………………… 13.8
13.5.2 Procedure for removing the sprocket from the roller…. 13-9
13.5.3 Procedure for reassembly of sprocket on the roller shaft.. 13-10
13.5.4 Procedure for removing splined shaft sprocket ……….13-11
13.5.5 Procedure for for reassembly of sprocket (splined shaft) 13-12
13.6 Netter clutch unit…………………………………………………… 13-13
13.7 Slip clutch settings/ torque adjustments………………………. 13-15
