McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
Section Page
McHale Fusion 2 contents section
02-vii
14. Trouble Shooting
14.1 Trouble shooting overview…………………………………. 14-1
14.2 Machine using higher than expected hp when chopping 14-1
14.3 Pick up slip clutch going off easily…………………………. 14-1
14.4 Rotor clutch going off easily…………………………………. 14-2
14.5 Knives not remaining up while chopping………………….. 14-2
14.6 Chamber losing pressure…………………………………….. 14-3
14.7 Machine making soft bales…………………………………… 14-3
14.8 Net will not feed during an automatic cycle……………….. 14-4
14.9 Net not cut correctly……………………………………………. 14-4
14.10 Net feeds in, in the middle of a bale…………………………. 14-5
14.11 Netting process complete but chamber door will not open 14-5
14.12 Safety switch error……………………………………………… 14-6
14.13 Bale transfer starts but bale fails to transfer to wrapper… 14-6
14.14 Wrapper will not start after bale transfer……………………. 14-7
14.15 Ring will not rotate even though the motors are rotating.. 14-7
14.16 Film break error when the film is not broken or run out…. 14-8
14.17 Dispenser breaking plastic……………………………………. 14-8
14.18 Cut and hold not going out all the way……………………… 14-9
14.19 Cut and hold not cutting clean………………………………… 14-9
14.20 Cut and hold releasing while the machine is baling………. 14-9
14.21 Wrapper not counting/ counting incorrectly………………… 14-10
14.22 Wrapper won’t index by a 1/2 rotation from the button…… 14-10
14.23 Dispenser moving out of position during work…………….. 14-11
14.24 Hydraulic wheel brake sticking………………………………… 14-11
14.25 Control box setting altered……………………..……………….. 14-11
15. Technical Specifications
15.1 General dimensions/ specifications…………………………….. 15-1
15.2 Tractor attachment…………………………………………………. 15-1
15.3 Machine specifications……………………………………………. 15-1
15.4 Tightening torque values…………………………………………..15-2
15.5 Tyre specifications…………………………………………………. 15-3
15.6 Deceleration of conformity……………………………………….. 15-3
