McHale Fusion 2 - Connecting Hydraulic Hosing to Tractor

McHale Fusion 2 tractor requirements section
06-6
McHale Fusion 2 round baler wrapper technical service manual
Issue 1: 0208
6.10 Attaching hydraulic hosing to tractor
Warning! When connecting hydraulic hosing to the tractor ensure that the
tractor engine is turned off and that the ignition key is removed. Ensure that all
hydraulic connections are correctly tightened.
There are a total of four hydraulic hoses that must be connected (3 on air
brake models)* to the tractor. They are as follows:
A. One ¾” male quick release for return line. Note: The return line must have a
free flow to tank. (Where a ¾” female coupling is not available on the tractor, a
½” male quick release is supplied with the Fusion 2 in the toolbox & should be
used to replace the ¾” coupling).
B. One ½” male quick release for feed line.
C. One ⅜” male quick release for load sensing (if tractor is load-sensing).
D. One ½” male quick release for pickup reel.
E. One hydraulic brake coupling.*
F1. One 12 V / 7 pin lighting socket.
G1. One 12 V / 20 Amp euro socket (Machine loom to control box shown).
H1. One break away rope fixed securely to the tractor.
See figure 6.10 below for possible piping layout.
Note: Ensure that machine operator is familiar with all tractor connections and
fittings.
*In the case of air brakes there must be two air brake couplings available.
Fig. 6.10 Possible layout of hydraulic
hosing and electric looms.
F1
A
B
C
D
E
G1
H1
