Measurands to be output Range
Measurands to be output Mx,min. ... Mx,max.
Scaled measurands to be output Mx,scal,min ... Mx,scal,max
with:
Mx,scal,min = (Mx,min - Mx,RL1) / (Mx,RL2 - Mx,RL1
Mx,scal,max = (Mx,max - Mx,RL1) / (Mx,RL2 - Mx,RL1
Designation of the set values in the data
model
"Scaled min. val. BCD" ... "Scaled max. val. BCD"
Measurands BCD display values
Measurands in the range "Measurands to
be output"
BCD-Out min. value ... BCD-Out max. value
(Valid BCD value)
Measurands:
Mx,RL1 = Mx = Mx,min
BCD-Out min. value (BCD value not valid)
Measurands Mx:
Mx,max = Mx = Mx,RL2
BCD-Out max. value (BCD value not valid)
Measurands Mx:
Mx < Mx,RL1
or
Mx > Mx,RL2
BCD-Out max. value (Overflow)
3 Operation P634
P634/EN M/R-42-A // P634‑311‑653 3-51
