3.11 Configuration and Operating Mode of the LED Indicators
(Function Group LED)
The P634 has 23 LED indicators for the indication of binary signals. Some of the
LED indicators are permanently assigned to fixed functions. The other LED
indicators are freely configurable. These freely configurable LEDs will emit either
red or green or amber light (amber is made up of red and green light and may
not be configured independently).
3.11.1 Configuring the LED Indicators
One binary signal can be assigned to each of the red and green LED color
indications. The same binary signal can be assigned to several LED indicators (or
colors), if required.
LED indicator Label Configuration
H 4 (red) TRIP With the P634 this LED indicator is customarily configured with
function MAIN: Gen. trip signal, but the configuration may
be modified.
H 4 (green) ― Function assignment to this green LED indicator is freely
configurable.
H 3 (amber) ALARM Permanently configured with function SFMON: Warning
(LED).
H 2 (amber) OUT OF SERVICE Permanently configured with function MAIN: Blocked/faulty.
H 1 (green) HEALTHY Not configurable. H 1 indicates the operational readiness of the
P634 (supply voltage is present).
H 17 (red) EDIT MODE Not configurable. H 17 indicates the input (edit) mode. Only
when the P634 is in this mode, can parameter settings be
changed by pressing the “Up” and “Down” keys. (See
Section 6.2, (p. 6-2))
H 5 to H 16
H 18 to H 23
― For each of these LED indicators both colors (red & green) may
be configured freely and independently.
3.11.2 Layout of the LED Indicators
The following figure illustrates the layout of LED indicators situated on the local
control panel.
P634
3 Operation
3-60 P634/EN M/R-42-A // P634‑311‑653
