8.2 Events
8.2.1 Event Counters
Parameter Address
Default Min Max Unit Logic Diagram
Main function
MAIN: No. general start.
004 000
0: don't execute Fig. 3-61, (p. 3-92)
[spacer]
Number of general starting signals.
[spacer]
MAIN: No. gen.trip cmds. 1
004 006
0: don't execute Fig. 3-63, (p. 3-94)
[spacer]
Number of general trip commands 1.
[spacer]
MAIN: No. gen.trip cmds. 2
009 050
0: don't execute Fig. 3-63, (p. 3-94)
[spacer]
Number of general trip commands 2.
[spacer]
MAIN: No. gen.trip cmds. 3
009 056
0: don't execute Fig. 3-63, (p. 3-94)
[spacer]
Number of general trip commands 3.
[spacer]
MAIN: No. gen.trip cmds. 4
009 057
0: don't execute Fig. 3-63, (p. 3-94)
[spacer]
Number of general trip commands 4.
Parameter Address
Default Min Max Unit Logic Diagram
Operating data
recording
OP_RC: No. oper. data sig.
100 002
0 0 1000 Fig. 3-71, (p. 3-105)
[spacer]
Number of signals stored in the operating data memory.
Parameter Address
Default Min Max Unit Logic Diagram
Monitoring signal
recording
MT_RC: No. monit. signals
004 019
0 0 30 Fig. 3-72, (p. 3-106)
[spacer]
Number of signals stored in the monitoring signal memory.
