Fig. 4-4: Flush-mounted case 84 TE with panel opening, flush-mount method 2 (with angle brackets and frame).
(Dimensions in mm.)
The device has increased mechanical robustness if flush-mount method 2 (with
angle brackets and frame) is used for the flush-mounted case.
4.2.2 Detachable HMI
Fig. 4-5: View of case 40 TE for connection of detachable HMI.
Fig. 4-6: View of case 84 TE for connection of detachable HMI.
