Micom P634 - Operating Data Recording

Parameter Address
Default Min Max Unit Logic Diagram
Binary counts
COUNT: Transmit counts USER
217 008
0: don't execute Fig. 3-184, (p. 3-228)
[spacer]
Count transmission.
[spacer]
COUNT: Reset USER
217 003
0: don't execute Fig. 3-184, (p. 3-228)
[spacer]
Count reset.
8.1.3 Operating Data Recording
Parameter Address
Default Min Max Unit Logic Diagram
Operating data
recording
OP_RC: Operat. data record.
003 024
0 0 1000 Fig. 3-71, (p. 3-105)
[spacer]
Point of entry into the operating data log.
Parameter Address
Default Min Max Unit Logic Diagram
Monitoring signal
recording
MT_RC: Mon. signal record.
003 001
0 0 30 Fig. 3-72, (p. 3-106)
[spacer]
Point of entry into the monitoring signal log.
P634 8 Information and Control Functions
8-160 P634/EN M/R-42-A // P634‑311‑653
