Micom P634 - Dimensional Drawings; Dimensional Drawings for the 84 te Case

4.2 Dimensional Drawings
4.2.1 Dimensional Drawings for the 84 TE Case
147.5 177.5 184.5
434.8
464.0
481.6
257.1
‑X6
Fig. 4-2: Surface-mounted 84 TE case. (Dimensions in mm.)
227.9
253.6
177.5
434.8
284.9
259.0
5.0
159.0 168.0
5.0
25.9
410.0
‑X6
Fig. 4-3: Flush-mounted case 84 TE with panel opening, flush-mount method 1 (without angle brackets).
(Dimensions in mm.)
P634
4 Design
4-4 P634/EN M/R-42-A // P634‑311‑653
