Q6Z0131A
Parameter
set 1
set 2
set 3
set 4
IDMT1:
Hold time P PSx
081 055
082 055
083 055
084 055
IDMT1:
Starting Iref,P>
[ 038 110 ]
Case A
Case B
Per characteristic
Non-delayed
Non-delayed
Per characteristic
Determ. trip time
IDMT1:
Hold time P running
[ 038 112 ]
IDMT1:
Starting Iref,P>
[ 038 110 ]
IDMT1:
Hold time P running
[ 038 112 ]
600 ms
400 ms
200 ms
IDMT1:
tIref,P> elapsed
[ 038 111 ]
Determ. trip time
600 ms
400 ms
200 ms
IDMT1:
tIref,P> elapsed
[ 038 111 ]
200 ms 200 ms
200 ms 450 ms
Fig. 3-124: The effect of the hold time illustrated for the phase current stage as an example
Case A: The determined tripping time is not reached.
Case B: The determined tripping time is reached.
3.24.7 General Starting
A general starting is triggered if the current in one phase exceeds the 1.05-fold
of the set reference current value. It can be selected whether the starting of the
negativesequence and residual current stages should be taken into account in
the general starting decision. The general starting triggers a timer stage. A signal
is issued when the time period of this stage has elapsed.
P634
3 Operation
3-172 P634/EN M/R-42-A // P634‑311‑653
