9.6 GOOSE Publishing
9.6.1 System/LLN0
Parameter Default Value
Network Parameters Multicast MAC Address 01-0C-CD-01-00-00
Virtual MAC address that the sending device provides as the destination; preset.
Application ID (hex) 0000
Explicitly (and uniquely) assigned ID-number of the GOOSE.
VLAN Identifier (hex) 0
ID-number of the virtual LAN with which the GOOSE is sent; preset.
VLAN Priority 4
Priority with which the GOOSE is sent in the virtual LAN; preset.
Parameter Default Value
Repeat Message
Transmission
Parameters
Minimum Cycle Time 10 ms
First send repetition of the GOOSE occurring after the set time period; preset.
Maximum Cycle Time 1 s
Continuous send repetition of the GOOSE occurring after the set time period;
preset.
Increment 900
Specification factor for the transition of time intervals for GOOSE send
repetitions from the first to the continuous repetition.
