9.1 Manage IED
The menu item “Manage IED” allows for establishing a connection between the
“IED Configurator” and the device.
The P634 features two memory “banks” one of which includes the active setting
parameters. The other memory bank is used with the configuration procedure for
parameters via “IED Configurator” or operating program.
Toggling between active and inactive memory bank is carried out either by
executing the parameter IEC: Switch Config. Bank or via “IED Configurator”
(after the connection has been established) by pressing the “Switch Banks”
button.
Parameter
Active Bank SCL File ID
Name of the configuration bank currently valid. Setting is carried out with the
IED Configurator, after a connection with the device has been established (via
menu item “Manage IED”).
SCL File Version
Version number of the configuration bank currently valid. Setting is carried out
with the IED Configurator, after a connection with the device has been
established (via menu item “Manage IED”).
Parameter
Inactive Bank SCL File ID
Name of the inactive configuration bank. Setting is carried out with the IED
Configurator, after a connection with the device has been established (via menu
item “Manage IED”).
SCL File Version
Version number of the inactive configuration bank. Setting is carried out with
the IED Configurator, after a connection with the device has been established
(via menu item “Manage IED”).
P634 9 IEC 61850 Settings via IED Configurator
9-2 P634/EN M/R-42-A // P634‑311‑653
