9 IEC 61850 Settings via IED Configurator
This chapter lists all IEC 61850-specific settings, that are carried out with the
configuration tool “IED Configurator”.
The sequence in which the settings are listed and described in this chapter
corresponds to their sequence in the menu tree of the “IED Configurator”.
However, only those setting parameters are described that are mandatory for
establishing the IEC 61850 communication.
Further setting parameters are listed in the “Settings” chapter under the function
groups IEC and GOOSE. A list of all available Logical Nodes can be found in a
separate document.
P634
P634/EN M/R-42-A // P634‑311‑653 9-1
