Micom P634 - PC Interface (Function Group PC)

3.4.1 PC Interface (Function Group PC)
Communication between the P634 and a PC is through the PC interface. In order
for data transfer between the P634 and the PC to function, several settings must
be made in the P634.
There is support software available as an accessory for P634 control.
64Z51ECA
PC:
Sig./meas.val.block.
[ 003 086 ]
MAIN:
Prot. ext. disabled
[ 038 046 ]
MAIN:
Test mode
[ 037 071 ]
0: No
1
0
1: Yes
PC:
Bay address
[ 003 068 ]
PC:
Device address
[ 003 069 ]
PC:
Baud rate
[ 003 081 ]
PC:
Parity bit
[ 003 181 ]
PC:
Spontan. sig. enable
[ 003 187 ]
PC:
Select. spontan.sig.
[ 003 189 ]
PC:
Transm.enab.cycl.dat
[ 003 084 ]
PC:
Cycl. data ILS tel.
[ 003 185 ]
PC:
Delta V
[ 003 055 ]
PC:
Delta I
[ 003 056 ]
PC:
Delta f
[ 003 057 ]
PC:
Delta t
[ 003 058 ]
PC:
Delta meas.v.ILS tel
[ 003 155 ]
PC:
Time-out
[ 003 188 ]
1
0
PC:
Command blocking
[ 003 182 ]
0: No
1: Yes
PC interface
Fig. 3-5: PC interface settings.
