9.2 IED Details
The category “IED Details” contains several settings that characterize the device
as well as the SCL file, which identifies the IEC 61850 configuration.
Parameter Default Value
SCL Details SCL File ID PX 634
Identification of the .MCL configuration file. If required, this preset value may be
modified by, for example, entering a bay name.
SCL File Version 243.2.01
Specific value to identify the IEC 61850 data model and configuration.
If required, this preset value may be modified by, for example, identifying the
revision states during engineering.
Parameter Address
IED Details Name
104 057
Explicitly assigned device name for the function in the system (IED); is part of
the Logical Device Name.
Important note: According to the IEC standard the name must consist of only
letters (A..Z, a..z), digits (0..9) and underscore characters (_), and the name
must start with a letter. Note that a non-standard name causes problems with
the IEC 61850 communication.
Parameter
Template Details ICD Template
SCL Schema Version
Description
Type
Configuration Revision
Supported Models
The values listed in the column “Template Details” only provide information.
They are preset and cannot be modified.
