Overload recording
OL_RC: No. overload
004 101
0 0 9999 Fig. 3-75, (p. 3-109)
[spacer]
Number of overload events.
Parameter Address
Default Min Max Unit Logic Diagram
Fault recording
FT_RC: No. of faults
004 020
0 0 9999 Fig. 3-82, (p. 3-119)
[spacer]
Number of faults.
[spacer]
FT_RC: No. system disturb.
004 010
0 0 9999 Fig. 3-82, (p. 3-119)
[spacer]
Number of system disturbances.
Parameter Address
Default Min Max Unit Logic Diagram
Definite-time over‐
current protection
DTOC1: No. general start.
009 150
0: don't execute Fig. 3-114, (p. 3-160)
[spacer]
DTOC2: No. general start.
009 160
0: don't execute
[spacer]
DTOC3: No. general start.
009 170
0: don't execute
[spacer]
DTOC4: No. general start.
099 001
0: don't execute
[spacer]
IDMT1: No. general start.
009 151
0: don't execute Fig. 3-126, (p. 3-173)
[spacer]
IDMT2: No. general start.
009 161
0: don't execute
[spacer]
IDMT3: No. general start.
009 171
0: don't execute
[spacer]
Number of general starting signals.
