values Mx,RL1 and Mx,RL2. (Mx,RL1 and Mx,RL2 are listed in the operating
program under “minimum” and “maximum”.)
Measurands Range
Measurands of the variable Mx Mx,RL1 ... Mx,RL2
Associated scaled measurands 0 ... 1
Measurands to be output Range
Measurands with knee-point to be output Mx,min ... Mx,knee ... Mx,max
Scaled measurands with a scaled knee-point to be
output
Mx,scal,min ... Mx,scal,knee ... Mx,scal,max
with:
Mx,scal,min = (Mx,min - Mx,RL1) / (Mx,RL2 -
Mx,RL1
Mx,scal,knee = (Mx,knee - Mx,RL1) / (Mx,RL2 -
Mx,RL1)
Mx,scal,max = (Mx,max - Mx,RL1) / (Mx,RL2 -
Mx,RL1
Designation of the set values in the data model "Scal. min. value Ax" ...
... "Scal. knee-point Ax"
... "Scaled max. val. Ax"
3.10.3.6 Associated Display Range
The associated display range is defined by setting the following parameters:
●
MEASO: AnOut min. val. A-1 or MEASO: AnOut min. val. A-2, resp.
●
MEASO: AnOut knee point A-1 or MEASO: AnOut knee point A-2,
resp.
●
MEASO: AnOut max. val. A-1 or MEASO: AnOut max. val. A-2,
resp.
Measurands Analog display values
Measurands in the range "Measurands to be
output"
"AnOut min. val. A-x" ...
... "AnOut knee point A-x" ...
... "AnOut max. val." (Value A-x valid)
Measurands:
Mx,RL1 = Mx = Mx,min
"AnOut min. val." (Value A-x not valid)
Measurands Mx:
Mx,max = Mx = Mx,RL2
"AnOut max. val." (Value A-x not valid)
Measurands Mx:
Mx < Mx,RL1
or
Mx > Mx,RL2
"AnOut max. val." (Overflow)
