End a End b End c End d
MAIN: Current Ineg a
prim.
(005 125)
MAIN: Current Ineg
b prim.
(005 129)
MAIN: Current Ineg
c prim.
(005 136)
MAIN: Current Ineg
d prim.
(005 140)
MAIN: Current Ipos a
prim.
(005 127)
MAIN: Current Ipos
b prim.
(005 134)
MAIN: Current Ipos c
prim.
(005 138)
MAIN: Current Ipos
d prim.
(005 146)
MAIN: Current Ineg a
p.u.
(005 126)
MAIN: Current Ineg
b p.u.
(005 130)
MAIN: Current Ineg
c p.u.
(005 137)
MAIN: Current Ineg
d p.u.
(005 145)
MAIN: Current Ipos a
p.u.
(005 128)
MAIN: Current Ipos
b p.u.
(005 135)
MAIN: Current Ipos c
p.u.
(005 139)
MAIN: Current Ipos
d p.u.
(005 147)
The positive- and negative-sequence current measured values of the virtual end,
formed by summation or subtraction of current values (primary and per unit
values), are also continuously determined and displayed as measured operating
data:
Positive-sequence current MAIN: Curr. Ineg,add p.u.
(005 149)
Negative-sequence current MAIN: Curr. Ipos,add p.u.
(005 150)
When the CB's contacts are open, it is also possible to force to zero the setting of
small positive- and negative-sequence current measured values if such
measured values are below additionally created settable thresholds.
Measured value relating to positive-sequence
current
MAIN: Meas.value rel. Ipos
(011 058)
Measured value relating to negative-sequence
current
MAIN: Meas.value rel. Ineg
(011 048)
