Micom P634 - Page 279

D5Z50BYA
LOGIC:
Output n
LOGIC:
Output n (t)
LOGIC:
Output n
LOGIC:
Output n (t)
LOGIC:
Output n
LOGIC:
Output n (t)
t2 = 0s
t1 = 0s
t1, t2 > 0s
t1 t1
t1 t1
t2 t2
t2 t2
Fig. 3-177: Operating mode 1: Pickup/reset delay (Oper./releas.delay). (This diagram is also valid for LOG_2, if the
signal parameters are replaced by the corresponding ones from LOG_2 .)
D5Z50BZA
LOGIC:
Output n
LOGIC:
Output n (t)
LOGIC:
Output n
LOGIC:
Output n (t)
LOGIC:
Output n
LOGIC:
Output n (t)
t2 = 0s
t1 = 0s
t1, t2 > 0s
t1 t1
t1 t1
t2 t2
t2 t2
Fig. 3-178: Operating mode 2: Pulse, delayed pickup (Oper.del./puls.dur.). (This diagram is also valid for LOG_2, if
the signal parameters are replaced by the corresponding ones from LOG_2 .)
3 Operation
P634
P634/EN M/R-42-A // P634‑311‑653 3-223
