Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LOGIC: Fct.assignm.outp.123
045 232
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm.outp.124
045 236
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm.outp.125
045 240
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm.outp.126
045 244
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm.outp.127
045 248
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm.outp.128
045 252
060 000: MAIN: Without function
[spacer]
These settings assign functions to the outputs.
[spacer]
LOGIC: Op. mode t output 1
030 001
0: Without timer stage Fig. 3-175, (p. 3-221)
[spacer]
LOGIC: Op. mode t output 2
030 005
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 3
030 009
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 4
030 013
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 5
030 017
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 6
030 021
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 7
030 025
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 8
030 029
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 9
030 033
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 10
030 037
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 11
030 041
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 12
030 045
0: Without timer stage
