Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
THRM2: Object temp. p.u. 2
004 208
Not measured -0.40 3.00 100°C
[spacer]
Display of the temperature of the protected object as determined by function
THRM1 or THRM2, respectively, referred to 100°C.
[spacer]
THRM1: Coolant temp. p.u. 1
004 206
Not measured -0.40 2.00 100°C Fig. 3-132, (p. 3-180)
[spacer]
THRM2: Coolant temp. p.u. 2
004 209
Not measured -0.40 2.00 100°C
[spacer]
Display of the coolant temperature of the protected object referred to 100°C.
[spacer]
THRM1: Temp. offset repl. 1
004 170
Not measured -25000 25000 % Fig. 3-132, (p. 3-180)
[spacer]
THRM2: Temp. offset repl. 2
004 190
Not measured -25000 25000 %
[spacer]
Display of the additional reserve if the coolant temperature is taken into
account. This display is relevant if the coolant temperature has been set to a
value below the maximum permissible coolant temperature or, in other words, if
the thermal model has been shifted downwards.
If, on the other hand, the coolant temperature and the maximum permissible
coolant temperature have been set to the same value, then the coolant
temperature is not taken into account and the characteristic is a function of the
current only. The additional reserve amounts to 0 in this case.
Parameter Address
Default Min Max Unit Logic Diagram
Overfluxing protec‐
tion
V/f: Excitation V/f p.u.
004 220
Not measured 0.00 10.00 Fig. 3-142, (p. 3-190)
[spacer]
Display of the V/f ratio, as a quantity referred to V
nom
/f
nom
.
[spacer]
V/f: Status replica in %
004 222
Not measured 0 100 % Fig. 3-147, (p. 3-194)
[spacer]
Display of the buffer content in % of the overfluxing protection function.
[spacer]
V/f: Status replica p.u.
004 223
Not measured 0.00 1.00 Fig. 3-147, (p. 3-194)
[spacer]
Display of the buffer content as a quantity referred to 100% of the buffer
content of the overfluxing protection function.
