Micom P634 - Page 582

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
GOOSE: Ext.Dev114 position
114 068
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev115 position
114 072
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev116 position
114 076
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev117 position
114 080
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev118 position
114 084
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev119 position
114 088
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev120 position
114 092
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev121 position
114 096
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev122 position
114 100
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev123 position
114 104
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev124 position
114 108
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev125 position
114 112
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev126 position
114 116
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev127 position
114 120
0: Interm. pos.
[spacer]
GOOSE: Ext.Dev128 position
114 124
0: Interm. pos.
[spacer]
State of the virtual two-pole GOOSE input, representing the state of an external
device.
[spacer]
GOOSE: Ext.Dev01 open
109 001
0: No
[spacer]
GOOSE: Ext.Dev02 open
109 006
0: No
[spacer]
GOOSE: Ext.Dev03 open
109 011
0: No
