Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
DIFF: Sat.discr. 1 trigg.
041 115
0: No Fig. 3-97, (p. 3-139)
[spacer]
DIFF: Sat.discr. 2 trigg.
041 116
0: No Fig. 3-97, (p. 3-139)
[spacer]
DIFF: Sat.discr. 3 trigg.
041 117
0: No Fig. 3-97, (p. 3-139)
[spacer]
DIFF: Trip signal
041 075
0: No Fig. 3-94, (p. 3-136)
[spacer]
DIFF: Trip signal 1
041 002
0: No Fig. 3-94, (p. 3-136)
[spacer]
DIFF: Trip signal 2
041 003
0: No Fig. 3-94, (p. 3-136)
[spacer]
DIFF: Trip signal 3
041 004
0: No Fig. 3-94, (p. 3-136)
Parameter Address
Default Min Max Unit Logic Diagram
Ground differential
protection
REF_1: Blocking EXT
019 051
0: No
[spacer]
REF_1: Enabled
041 132
0: No Fig. 3-99, (p. 3-142)
[spacer]
REF_1: Ready
019 054
0: No Fig. 3-99, (p. 3-142)
[spacer]
REF_1: Trip signal
041 005
0: No Fig. 3-103, (p. 3-148)
8 Information and Control Functions P634
P634/EN M/R-42-A // P634‑311‑653 8-91
